For installers and professionals
- 19 -
Parallel connection with filtration clock
Note: The installer should connect A parallel with B (as above picture). To start the water
pump, condition A or B is connected. To stop the water pump, both A and B should
be disconnected.
A: Water pump timer
B: Water pump wiring of Heat Pump
