Max. PV input
voltage(Voc)
40 V
60 V
/
/
PV optimum operating
voltage(Vmp)
18 V ~ 32 V
29V ~ 48 V
/
/
Max.PV. power
120W / 240W /
360W / 480W
240W / 480W /
720W / 960W
/
DC Outputs (for –DC series only)
Model
5V (2A), 9V / 12V (1A), 15V / 24V (1A),
2pin socket: 12V (10A)
Other
1x PoE, 2x USB 5B (2A)
Others
Protections
Overload – short-circuit – overvoltage – undervoltage – overcharge –
overtemperature – excessive low battery – missing insert
Interface
LCD & BUZZER
Operating
temperature
0℃ ~ 40℃
Operating humidity
Relative humidity ≤ 93%
Altitude
< 1000m, (above 1000m, derating 1% for each additional 100 m),
4000 m max.
Net weight (kg)
8.0/8.5/7.4
10.9/11.4/11
14.0/14.6
18.0/18.5
32.0
36.0
Gross weight (kg)
9.0/9.5/8.4
11.9/12.4/12
15.0/15.6
19.0/19.5
34.0
38.0
Dimensions (W×D×H)
mm
280×258×120 (w/o option)
293×280×160 (w/ option)
400×210×127 (Wall
mounted)
293×280×160
302×479×209
Packaged dimensions
(W×D×H) mm
330×352×200 (w/o option)
370×355×235 (w/ option)
490×290×195 (Wall
mounted)
370×355×235
353×582×287
Note: Specifications are subject to change without notice；MPPT modules and DC modules are optional.
Charging features
Charging
process
Three-stage:
CC (constant current) CV (constant voltage) Float (floating charge)
Process
diagram
Constant voltage charging time: 60 S
