2 Product Overview
2.1 Specifications
MODEL
300W
600W
1000W
1600W
2500W
3500W
DC Input (the inverter must be connected to batteries to work properly)
Nominal input voltage
12V
24V
DC input range
10 ~ 15V
20 ~ 30V
AC Input
Bypass input range
0 ~ 264Vac for 220Vac/230Vac/240Vac,
Mains input range
150 ~ 282Vac for 220Vac; 156 ~ 294Vac for 230Vac;
163 ~ 307Vac for 240Vac;
Input frequency range
50Hz / 60Hz (Auto-sense& Settable:5% ~15%,default 15%),
42.5 ~ 57.5Hz for 50Hz, 51 ~ 69Hz for 60Hz
Input range of the
generator
99 ~ 282Vac for 220Vac; 104 ~ 294Vac for 230Vac;
108 ~ 307Vac for 240Vac;
No AVR in generator mode
Input frequency range
of the generator
40 ~ 70Hz
Input power matching
of the generator
Rated power 10% ~ 150%,
regulating step 10%，default 120%
Output
Inverter output range
220Vac / 230Vac / 240Vac ± 5% or
Bypass output range
0 ~ 264Vac for 220V/230V/240V,
Mains output range
174 ~ 242Vac for 220Vac; 182 ~ 253Vac for 230Vac;
190 ~ 264Vac for 240Vac;
Output frequency
50Hz / 60Hz ± 0.3 (Auto-sense & settable)
Output waveform
Pure sine wave
Output power
300W
600W
1000W
1600W
2500W
3500W
Putput sockets
2x schuko CEE 7/3
Block terminal
Efficiency
Max. 95% (Mains mode); Max. 80% (Inverter mode)
ECO mode
Settable, load<3%,enter in 80 s
No-load shutdown
Settable, time can be set (1 ~ 99 min), load can be set (3% ~ 50%)
Transfer time
≤ 10 ms
≤ 15 ms
Power factor
1.0
THDV
< 5% (linear load)
Inductive load
Yes
Motor load
Yes
Rectifier load
Yes
Overload capability
Mains mode: 110% 120 s; 125% 60 s; 150% 10 s (switch to bypass)
Inverter mode: 110% 60s; 125% 10 s; 150% 10s (shut down)
Battery
String battery q-ty
1
1
1
2
2
2
Charging current
(selectable)
Default
10A
Default 20A, regulating step 1A (< 10A) / 5A (> 10A)
Max. 15A
Max. 30A
Max. 40A
Max. 40A
Max. 50A
Max. 60A
Equalizing charge
voltage
Single battery 14.4Vdc (default), 13.6 ~ 15Vdc settable
Floating charge
voltage
Single battery 13.7Vdc (default), 13.2 ~ 14.6Vdc settable
DOD
Single battery 10.8Vdc (default), 9.6 ~ 13Vdc settable
EOD
Single battery 10.2Vdc (default), 9.6 ~ 11.5Vdc settable
Reverse warning
Buzzer
Alarm
Switch on / off
Continuous beep 2 s
Low battery
Beep 0.2 s at interval of 0.4 s
Overload
Beep 2 s at interval of 2.5 s
Mains power
abnormal
Beep 0.3 s at interval of 5 s
MPPT Modules (for –DC series only)
Model
40A
/
/
