2.2 Front panel features
300W ~ 1600W front panel 300W ~ 600W front panel
Tower type Wall mounted type
2500W ~ 3500W front panel
2.3 Rear panel features
300W ~ 1600W rear panel
① AC input socket
② Output sockets
③ Overcurrent protector
④ Buzzer for battery reverse
⑤ Battery wiring
⑥ Battery breaker
⑦ Fan
Tower type
Wall mounted type
