Contents
1 General safety instructions .............................................................. 3
2 Technical data and dimensions ....................................................... 4
Technical data ................................................................................ 4
Dimensions ..................................................................................... 5
3 Installation and connection ............................................................. 6
Ground ............................................................................................ 6
Removing the transport brackets .................................................... 6
Water connection ............................................................................ 6
Water drain ..................................................................................... 7
Main power connection .................................................................... 7
Steam connection ........................................................................... 8
4 Operating instructions ..................................................................... 9
Machine with CAM-timer and 10 buttons ......................................... 9
Machine with electronical PLC-9 microprocessor and start button ... 12
5 Technical remarks ............................................................................ 16
Program time (Machine with CAM-timer) .......................................... 16
Internal connection of the electrical heating .................................... 17
Internal connections of the motor .................................................... 17
Thermo-magnetic motor protection .................................................. 18
Tilt switch and electronical repetition system .................................. 19
6 Maintenance of the machine ........................................................... 20
Code: 249/00026/01
08/09/94
