Iradion Infinity Series - Indicator Lights Details

20
Indicator Lights Details
The following chart is provided for clarity and is specific to the 1625 water cooled laser:
RED
FAULT
off
on
on
blink
on
blink
blink
YELLOW
WARN
on
on
off
on
blink
blink
off
Condition:
A
B
C
D
E
F
G
A = Getting hot warning, but no fault condition.
B = System faults: too hot/water too hot.
C = System fault: over/under voltage, other faults.
D = No air flow (system in continuous fault)
E = No or low water flow, too much water flow/pressure (system in continuous fault)
F = In the 1625 configuration, this state is not allowed.
G = CPLD failure
Note: A blinking red light is the same level of fault as a solid red light.
