Iradion Infinity Series - Service Disconnect

26
Danger - Serious Personal Injury
Service Disconnect
When servicing the laser or its power supply, the Service Disconnect must be
detached for safety. The Service Disconnect is the NEMA L6-20 Plug/Receptacle
found on the rear of the Power Supply/Air Pump Unit.
Danger - Serious Personal Injury
Mating Connector
The power supply and air pump unit is supplied with a NEMA L6-20R connector for
the primary power connection.
All local electrical and fire codes must be followed.
NEMA L6-20 Service
Disconnect
