iRay Technology GL35R - 1 Specification; Microbolometer and Optical Characteristics; Operational and Rangefinder Characteristics

InfiRay Outdoor • Geni GL35R Series • Quick Start Guide www.infirayouordoor.com
All rights reserved and shall not be copied and distributed in any form without written permission
1 Specification
Model
Geni GL35R
Microbolometer
Resolution, pixels
384 × 288
Pixel size, μm
12
NETD, mk
≤40
Frame rate, Hz
50
Optical Characteristics
Objective lens, mm
35
Field of view
7.5° × 5.7°
Magnification, x
2.81 - 11.24
E-zoom, x
1 / 2 / 3 / 4
Diopter Adjustment, D
-5 ~ +5
Detective range, m
(Target size:1.7m*0.5m, P(n)=99%)
1818
Display
Display type
OLED
Resolution, pixels
1024 × 768
Power Supply
Battery type
26650 × 1
External Power Supply
5V (Type C USB)
Max. Operation time (at t=22℃), h
★
7
Operational Characteristics
Max. Recoil Power on Rifled
Weapon, g/s²
1000
Degree of protection, IP code
IP67
Amount of built-in memory, Gb
32
Operating Temperature Range, ℃
-10 ~ +50
Weight (without batteries), g
< 600
Dimension, mm
225 × 100 × 61.5
Rangefinder Characteristics
Wavelength, nm
905
Max. Measuring Range, m/y
★★
1000
Measurement Accuracy, m
±1
★
The actual operating time depends on the intensity of using Wi-Fi,
video recorder.
★★
The measuring range depends on the characteristics of the object
under observation and environmental conditions.
➢ Improvements may be made to the design and software of this product
to enhance its useful features.
➢ Technical parameters of the device may be improved without prior
notice of the customer.
