Name and function of components
Function
1.Head cushion
2.3D digital audio
(left built-in voice-
controlled microphone)
3.Upper arm air
pressure component
4.Arm air pressure
component
5.Manual controller
or mobile phone
placement slot
6.USB charging port
7.Seat cushion
8.Leg rest
9.Foot rest
10.Backrest
11.Armrest
12.Handrail shortcut key
13.Embedded lamp
14.side cover
15.Back cover
16.Manual controller
17.Drive box cover
18.Move pulley
19.Power cord and plug
20.Safety box
21.Power switch
22.Power line socket
15
17
19
16
18
20
21 22
FUSE:
T5AL 250V
POWER INPUT
ON/ OFF
·This product has designed a set of massage manipulator that can walk up and down,
four-wheel drive and mute design.
·There are five simulative massage techniques: finger pressing, kneading, tapping,
tapping and kneading at same time.
·Equipped with shoulder automatic positioning detection.
·Automatic massage functions: automatic massage includes 12 kinds of automatic
massage functions, including comfortable massage, relaxing massage, traction
massage, shoulder and neck massage, back and waist massage, whole body
massage, Protection of vertebral massage, fatigue recovery, stretching muscles and
activating collaterals, beautiful buttock shaping, soothing sleep and full air pressure.
·Equipped with upper body manual massage function (the whole body, fixed point and
local three massage parts are selected, and the speed of each massage manipulation
can be adjusted with five speed. In fixed point and local state, the manipulator can
adjust the position up and down; When tapping, pressing and percussion massage, the
width of the massage ball can be wide, medium or narrow.
·It has air pressure massage function: upper arm air pressure massage function (built-in
4 airbags), arm air pressure massage function (built-in 8 airbags), calf air pressure
massage function (built-in 16 airbags), and 3rd air pressure intensity adjustment.
·It has intelligent voice recognition function and intelligent voice control wake-up button
on the left armrest.
·The calf frame is provided with a telescopic adjustment function, and the calf foot is
pulled out with the ankle. The length of the foot extension can be determined according
to the length of the user's leg, and the foot is retracted by the spring force to adapt to
different heights of the person.
·It has a separate lifting and lowering function for the calf frame, a linkage adjustment
function for the backrest frame, zero gravity, and timing adjustment.
·With back heat treatment function: carbon fiber as far infrared heat source.
·Under the backrest frame, the backrest adopts slide rail technology to keep the zero
space against the deviation wall all the time, so as to save the space to the greatest
extent.
·Backrest frame guide adopts curve guide technology, which completely conforms to the
curve of human back, and can enjoy massage from head to thigh.
·Music playback system, 3D digital audio built into left and right upper arms. Use the
Bluetooth function of the smart device to play music wirelessly.
·The foot has a foot roller massage function, and a set of rollers roll the rolling scraping
massage on the arch of the foot.
·The front end of the right armrest is provided with a manual control slot or a mobile
phone slot, and has a USB charging function.
·There are five kinds of handrail shortcut keys on the left handrail, such as the opening
key, the calf frame lifting button, the linkage adjustment button, the automatic mode
button, and the voice wake button.
·The left and right handrails are equipped with LED mood lights.
·LCD Color screen controller.
·Shutdown automatic sitting function, manipulator automatic reset function.
1
2
3
4
8
10
11
7
12
14
6
5
9
13
