iRest A380 - Page 5

CON26: 24VA/+5VB to the
main board
CON28: 12V/5V to armrest
LED light
CON30: AC22V to main
board
CON35: 24A/12V to main
board
CON32：2 sets of AC22V to
the transformer
CON23: AC19V to the
transformer
CON22：Switch power to the main
board’s +5VA and start signal
CON11：AC220V Input
CON16 ： AC220V to the
transformer
Figure 2: Instruction of adapters on the power board
