RC8221 Iris
™
Camera
Ceiling Mounting
Step 1: Disassemble the iron plate
a. Screw the swivel connector off the stand. Then use the screwdriver to
remove the screw of the stand base.
b. Disassemble the iron plate from the bottom of the stand.
Step 2: Install mount screws
a. Place the iron plate in the desired position of the ceiling. Screw the
mounting screws into ceiling through the 2 round holes of the iron plate.
Step 3: Mount the camera
a. Use the screwdriver to tighten the screw of the stand base.
b. Attach the swivel connector to the base by turning clockwise.
