Central heating
boiler type
IRLEH
2. Three-way valve 3. Circulation pump 4. Differential valve 5. Heater 6. Tap water heater 7. Inlet of cold water 8. Valve 9. Tap water outlet 10. Expansion tank “closed” 11. Connecting piece with
sockets
12. Filter 13. Thermoregulatory valve
type TERMOWAR 61
o
C
14. The naiant manageable
clack without the spring
15. Venting 16. Control valve 17. Cooling valve:
Honeywell TS130 – ¾ A (95
o
C)
WATTS STS 20 (97
o
C)
18. Cold water inflow 2-6 bar, 10-15
o
C
19. Manometer 20. Security valve
WARNING!
–
If the security valve on a cooling
coil against overheating is installed, it is possible not to use the floating back flap at the bypass.
On special user demand the installation can be expanded with accumulation tanks (1,2 or 3 pieces even), room and outside temperature sensor or thermal outlet protection. There’s also a possibility to combine two boilers within cascade. Such modification must be performed based on separate documentation of
installation designed by the authorized designer.
2
4
. S
ample central heating system
in
the
closed system
.
The schema No. 1 Basic - recommended by the producer Variant I Variant II Variant III
