iRobot Roomba i1 User Manual

Roomba
®
i1/i3/i4 Owner’s Guide 7
EN
Pinch the brush frame release
tab, lift the tab, and remove any
obstructions.
Remove the brushes from the
robot. Remove the brush caps
from the ends of the brushes.
Remove any hair or debris that
has collected beneath the
caps. Reinstall the brush caps.
Cleaning the Multi-Surface Brushes
Remove any hair or debris
from the square and
hexagonal pegs on the
opposite side of the brushes.
Remove the bin from the
robot and clear any debris
from the vacuum path.
Reinstall the brushes in the robot.
Match the shape of the brush pegs
with the shape of the brush icons in
the cleaning head module.
1
2
3
4
5
Cleaning the Front Caster Wheel
Pull firmly on the front wheel module to remove it
from the robot.
Pull firmly on the wheel to remove it from its
housing (see illustration below).
Remove any debris from inside the wheel cavity.
Reinstall all parts when finished.
Make sure the wheel clicks back into place.
Important: A front wheel clogged with hair and debris
could result in damage to your floor. If the wheel is not
spinning freely after you have cleaned it, please contact
Customer Care.
1
2
3
4
Wheel
Axle
Housing

iRobot Roomba i1 Specifications

General

Shape	Round
Color name	Rye
Product color	Gray
Remotely operated	Yes
Dust container type	Bagless
Noise level	- dB
Wet mopping	No
Dust capacity (total)	0.4 L
Base station functions	Charging
HEPA filtration system	-
Package type	Box
Package depth	420 mm
Package width	450 mm
Package height	127 mm
Package weight	4700 g
Master (outer) case width	475 mm
Master (outer) case height	150 mm
Master (outer) case length	435 mm
Master (outer) case weight	5200 g
Quantity per master (outer) case	1 pc(s)
Master (outer) case GTIN (EAN/UPC)	5060629987132
Battery capacity	- mAh

Weight and Dimensions

Depth	342 mm
Width	340 mm
Height	92.5 mm
Weight	3180 g
