Iron Edison REVOLT4 - Product Specifications; Battery Specifications

5
www.ironedison.com
2.1 Product Specifications
System Model (see nameplate) IE51100RV4
Model Code
IE
Nominal Voltage
51.2
Nominal Capacity
100 Ah
Battery Type
LiFePO4
Model Number
REVOLT4
2.2 Battery Specifications
Item
Specification
Battery Type
LiFePO4
Nominal Voltage
51.2
Nominal Capacity
100Ah
Nominal Energy
5.12 kWh
Standard Charge Voltage
55.2 V
Recommended Float Charge Voltage
53.4 V
Maximum Continuous Charge Current
100 A
Maximum Continuous Discharge Current
100 A
Peak Discharge Current (3 seconds)
300 A
Maximum Continuous discharge power
5 kW
Peak Discharge Power (3 seconds)
15 kW
Weight
127 LBS
