Ironside ICT 7000 User Manual

Overrange indication: LCD will display “OL”
Low battery:
will appears on LCD
Jaw capability: 40mm, Max conductor size
Power: Battery 1.5V×3 Size AAA
Size: 225mm×86mm×32mm
Weight: Approx. 330g
Operating: 5°C to 35°C
Storage temperature: −10°C to 50°C
DC VOLTAGE
Range
Resolution
Accuracy
6V
1mV
±（0.8%of rdg +5 digits）
60V
10mV
600V
0.1V
1000V
1V
±
（
1.0%of rdg +2 digits
）
Input Impedance: 10MΩ
Overload Protection: 1000V DC or 700V AC RMS
AC VOLTAGE
Range
Resolution
Accuracy
6V
1mV
±（1.2%of rdg +5 digits）
60V
10mV
600V
0.1V
700V
1V
±
（
1.2%of rdg +8digits
）
Input Impedance: 10MΩ
Frequency range: 40Hz to 400Hz
Overload Protection: 1000V DC or 700V AC RMS
AC CURRENT
Range
Resolution
Accuracy
600 A
0,1 A
±
（
2.5%of rdg +5 digits
）
1000 A
1 A
±
（
3.0%of rdg +5 digits
）
Frequency range: 50Hz to 60Hz
Overload Protection: 120% ranges for 60 seconds max
RESISTANCE
Range
Resolution
Accuracy
600Ω
0,1Ω
±（1.0% of rdg +3 digits）
6 kΩ
1Ω
60 kΩ
10 Ω
600 kΩ
0,1 kΩ
6 MΩ
1 kΩ
60 MΩ
10 kΩ
±
（
5.0% of rdg +5 digits
）
Overload Protection: 250V DC or AC rms, ac for all ranges
CAPACITANCE
Range
Resolution
Accuracy
600 nF
0,1 nF
±（4.0%of rdg +5 digits）
6 uF
1 Nf
60 uF
10 Nf
600 uF
0,1 uF
1000 uF
1 uF
Overload Protection: 250V DC or AC rms, ac for all ranges
ADP
Range
Resolution
Accuracy
600mV
0.1mV
±
（
3.0%of rdg +5 digits
）
FREQUENCY
Range
Resolution
Accuracy
40 Hz
1 Hz
±（0.1% of rdg +2digit）
6
