Overload Protection:10V DC or RMS,AC for all ranges
Measurement range: 1V to 10V rms, 40Hz to 100kHz
AUDIBLE CONTINUITY AND DIODE
If continuity exists (about less than 40Ω), built-in buzzer will
sound.
Show the approx, Forward voltage of the diode.
AUTO POWER OFF
To extend the battery life, Auto Power Off function is provided. If no key operations of range changing
happen about 10 minutes, the meter will be turned off automatically.
To turn it on, pushing the FUNC. Button only.
REPLACING THE BATTERY
WARNING
To avoid electrical shock or personal injury, remove the test
leads and any input signals before replacing the battery.
Replace only with same type of battery
When the electrical tester displays the “
” mark or the backlight be not much lit, the battery must be
replaced to maintain proper operation. Use the following procedure to replacing the battery:
1. The Rotary Switch is used to select OFF. Disconnect test leads from any live source and remove the
test leads from the input terminals.
2. Remove screws on the battery cover and open the cover.
3. Remove the exhausted battery and replace with three new 1.5V size AAA batteries.
Place battery cover and secure by a screw.
WARNING
Using this appliance in an environment with a strong radiated
radio-frequency electromagnetic field (approximately 3V/m) may
influence it measuring accuracy
ACCESSORIES
• Operator’s instruction manual
• Set of test leads
• Gift box
• Battery 1.5V×3 Size AAA
At the end of the product’s useful life, please dispose of the
device at collection points provided in your community.
7
