Semi-Auto/Manual Button
• Manually starts an automatic program (semi-auto) or an individual valve.
Next Button
• Advances to the next option for setting time/date and special features.
Dial
• Sets changes or checks program information.
+/- (Plus/Minus) Buttons
• Changes the values of program information. Can be used one step at a time or held
down longer to rapidly advance to another setting. Holding down either button for
longer than 3 seconds causes the display to rapidly scroll through the digits.
Display
• Shows the value of the selected information.
Time
• Sets the correct time of day on the controller. Note the AM/PM display.
Date
• Sets the correct year, month and day on the controller.
Rain Sensor Switch (located on the circuit board)
• Bypass position disables rain sensor function and allows the controller to operate
without a rain sensor connected.
What the Buttons and Switches Do continued...
12
