ISE POWER TOWER - STEP 2: Upright and Handlebar Attachment

STEP 2
1. Attach the Up Upright Frame (7) to the Down Upright Frame (3).
2. Attach the Handle Tube (4) and Back Cushion Tube (9) to the Up Upright Frame (7)
and Down Upright Frame (3), using four M10X70mm Hex Bolts (25), eight M10
Washers (33) and four M10 Nylon Nuts (35).
3. Attach the High Pull (8) to the Up Upright Frame (7), using two M8X 5mm Carriage
Bolt (27), two M8 Washers (32)
and two M8 Nylon Nuts (34).
4. Insert Handle Tube (12) into the Down Upright Frame (3).
-3-
ASSEMBLY INSTRUCTION
8
7
7
4
4
3
3
8
9
12
12
25
25
25
25
25
25
27
27
32
32
33
33
33
33
33
33
33
33
33
33
33
33
34
34
35
35
35
35
35
