EDS E16D0_443
E16D1_443
E24D1_552
Serialnumber (6 digits) 71xxx0/1
Serialnumber (6 digits) 71xxx0/1
Serialnumber (6 digits) 71xxx0/1
EBS E08B0_211 Serialnumber (6 digits) 77xxx0/1
ESS ESS01C_120 Serialnumber (7 digits) 77xxxxx
4 Technical data
System
System MMS – Eurocassette 6U
Connectivity
System connector 96pin backplane
USB - front 1x USB-A
USB - board 1x USB-A For manufacturer specific WiFi
adapter
Ethernet (10/100/1000 MBit) 1x RJ-45
CAN 2x RJ-45 Two seperate lines (green and
yellow indication)
Control connector 1x D-SUB-9 female Custom specific configurable, refer
to page 11
Server hardware
CPU Freescale iMX6 Quad-Core 996 MHz
RAM 1 GB DDR3 onboard
Flash Memory 4 GB onboard
Operating system
ICS2 Manufacturer specific Linux distribution
Services iCSservice (Websocket, HTTP, SOAP), SNMP, EPICS, HALservice
Native control software isegControl (Win 7/8/10 – 32/64bit, Linux, OS X 10.9 and higher)
Web browser based control /
config software
iCSconfig / iCScontrol: All plattforms: Mozilla Firefox (version > 41),
Google Chrome (version > 45), iOS (Safari): version > 7
Environmental conditions
Operating temperature range 10 – 40 °C
Storage temperature range -20 – 85 °C
Humidity 30 – 70 % (non condensating)
Compliance
RoHS, CE, UL-94, Conflict Mineral, REACH
5 Hardware setup and topology
An ECH crate which is equipped with a CC24 Host Controller can be extended with up to 2 x 4 CC23 slave controllers using the
green and the yellow daisy chain CAN lines. Legacy CAN controlled crates can be connected at the end of each of these lines.
All CC2x controllers provide two independent CAN lines, that are separated by color coding, indicated by the LED of the CAN
connector. The upper CAN connector connects the YELLOW CAN LINE, the lower to the GREEN CAN LINE.
The address IDs of the connected crates are configured automatically, depending on the position in the chain following this
pattern:
