The voltage supply of the crates backplane and the crate connected modules is switched on by the POWER ON pushbutton or
REMOTELY.
Normal front panel operation
Hold the POWER ON pushbutton for one second. The power supply will be switched on. LED STATUS turns to GREEN. By holding
the POWER ON pushbutton again for one second, the power supply will be switched off. The LED STATUS goes OFF.
INFORMATION
NOTE
If the POWER ON pushbutton will be hold for five seconds, the crate enters the configuration mode (see
pg. 12)!
Front panel operation with errors
If an error occurs while trying to switch the Crate on, the LED STATUS lights RED for 5 seconds. After that the crate controller
shuts down the operation and the LED STATUS goes OFF. If an error occurs during operation, the crate remains powered on and
the LED STATUS is permanent RED.
All possible errors are described in the Crate Status register description (see CAN EDCP programmers guide – page Fehler:
Referenz nicht gefunden).
7 Safety-Loop connector
The SL1 and SL2 connectors serve as current source for the safety loop. The current flow through a safety loop enables the high
voltage generation within the modules. When the safety loop is interrupted, the high voltage generation stops immediately.
INFORMATION
NOTE
The safety loop feature has to be activated by removing of a jumper on the backside of the modules also,
see specific module manual for more information.
