20
isel-CNC Compact Equipment CPM
7 Technical data / accessory
CPM 2018 CPM 3020 CPM 4030
Measurements w x d x h [mm] 515 x 580 x 615 610 x 655 x 705 710 x 820 x 750
Movement areas X/Y/Z [mm] 200/175/90 295/200/130 395/300/140
maximum axis speeds [mm/s] 50 50 50
(without a load) all axes with 10 mm leadscrew pitch
Pass-through height [mm] 90 115 160
Clamping table [mm] 250 x 425 250 x 500 375 x 600
T-slot raster [mm] 25 25 25
Type 2 and 3
Approx. weight [kg] 71 76 89
Sound pressure level 78 decibel (A) 78 decibel (A) 78 decibel (A)
Mains rating 230 V, 50 Hz, 16 Amp
Max. power consumption 1150 W
Fusing power input 2 x 6.3 Amps, slow-blow HBD
Earthing corresponds to protection class I.
Electric connections 2 x 24 V, optional, switchable, 20 mA via optical isolator
1 x 230 V, optional, switchable, 100 W
1 x 230 V, switchable for the tooling machine
Tooling machine (model 3) 500 W, 11.000 - 25.000 r.p.m., firmly wired
EMC test according to EN 55011-B and EN 50082-1
Technical subject to change
7.1 Accessories
You can order the following accessories that matches the CPM: Order no.:
- additional collets for the spindle: e. g. 239 110 3000
1 to 5 mm in 0,5 mm steps, 6 mm and 1/8"
- additional mounting hardware for the T-slot plate e. g. 290 002
- working area light (not for type 1) 280 1XX 9004
- suction apparatus 280 1XX 9001
- vacuum cleaner 425 005
- engraving spindle (25 000 r.p.m.) with mech. hight offset 421520
- engraving pad 280 1XX 9003
- sprinkle/chilling appliance 280 1XX 9002
- axis of rotation on inquires
- grease gun 931 170
- length measurement unit 280 110 9010
With every accessory, pay attention to an expert assembly and consider the valid standards
and safety regulations.
In the appendix, you find the assembly and operating instructions for the accessories.
For further information and/or purchase orders, please turn to Technical consulting
CNC systems phone +49-6672-898-218, -489, -215
fax +49-6672-898-222
email system-sales@isel.com
