ICP 2015 ICP 3020 ICP 4030
Measurements w x d x h [mm] 535 x 600 x 690 610 x 650 x 715 780 x 850 x 810
Movement areas X/Y/Z [mm] 200/150/90 300/200/90 400/300/140
maximum axis speeds [mm/s] 50 50 50
(without a load) all axes with 10 mm leadscrew pitch
Pass-through height [mm] 100 115 170
Clamping table [mm] 250 x 400 250 x 500 375 x 600
T-slot raster [mm] 25 25 25
/Þ«iÊÓÊ>`ÊÎ
Approx. weight [kg] 78 85 89
Sound pressure level 78 decibel (A) 78 decibel (A) 78 decibel (A)
Mains rating 230 V, 50 Hz, 16 Amp
Max. power consumption 1150 W
Fusing power input 2 x 6.3 Amps, slow-blow HBD
Earthing corresponds to protection class I.
Electric connections 2 x 24 V, optional, switchable, 20 mA via optical isolator
1 x 230 V, optional, switchable, 100 W
1 x 230 V, switchable for the tooling machine
Tooling machine (model 3) 500 W, 11.000 - 25.000 r.p.m., firmly wired
EMC test according to EN 55011-B and EN 50082-1
In order to improve our products, we reserve the right to make engineering changes.
Ç°£ VViÃÃÀÞ
You can order the following accessories that matches the ICP: "À`iÀÊ°\
- additional collets for the spindle: e. g. 239 110 3000
1 to 5 mm in 0,5 mm steps, 6 mm and 1/8"
- additional mounting hardware for the T-slot plate e. g. 290 001
- drill and milling cutter set, shaft 3 mm / 3,175 mm 400 100/400 200
7 drills (0,5 - 3 mm), 8 milling cutters (1 - 3 mm and/or 1/8"), 2 burins
- working area light (not for type 1) 280 1XX 9004
- suction apparatus 280 1XX 9001
- vacuum cleaner 425 005
- engraving spindle (25 000 r.p.m. and/or 20 000 r.p.m.) 421520/421503 0001
- engraving pad 280 1XX 9003
- sprinkle/chilling appliance 280 1XX 9002
- axis of rotation e. g. 263 003 0001
- grease gun 931 170
With every accessory, pay attention to an expert assembly and consider the valid standards
and safety regulations.
In the appendix, you find the assembly and operating instructions for the accessories.
For further information and/or purchase orders, please contact our
ÌiVV>ÊVÃÕÌ}Ê+49-6659-981-744
