Capacitance
Range Resolution Full Scale Test Current
Accuracy (1 year
23˚C ±5˚C) [1]
5nF: 0.5~1nF [2]
0.001nF 5.100 8.3A
2.0%+20
5nF: 1~5nF [2] 2.0%+10
50nF: 5~10nF [2]
0.01nF 51.00 8.3A
2.0%+30
50nF: 10~50nF [2] 2.0%+10
500nF 0.1nF 510.0 83A
2.0%+4 5F 1nF 5.100 0.56mA
50F 10nF 51.00 0.83mA
[1] For the 5nF ~ 50F range, make sure that the input is greater than 10%
of the range.
[2] Need to use the REL function.
* Input protection of 500V peak on all ranges.
Frequency
Measurement Range Accuracy (1 year 23˚C ±5˚C)
10Hz ~ 500Hz 0.01%+5
500Hz ~ 500kHz 0.01%+3
500kHz ~ 1MHz 0.01%+5
* AC + DC measurements do not allow frequency measurements.
* Input protection of 1000V peak on all ranges.
Voltage Measurement Sensitivity
Range
Minimum Sensitivity (RMS sine wave)
10~100kHz 100k~500kHz 500kHz ~ 1MHz
500mV 35mV 200mV 500mV
5V 0.25V 0.5V 1V
50V 2.5V 5V 5V
500V 25V uncal uncal
750V 50V uncal uncal
