16
5.3 Measuring currents
1. Plug the black lead into the "COM" input terminal of the meter. To measure currents up to a maximum of 400 mA plug the
red lead into the "mA" input terminal and to measure currents up to a maximum of 10A plug it into the "A" input terminal.
(The meter can also measure and display currents of up to 20A but currents of this level must not be applied to it for more
than 30 seconds.)
2. Turn the function switch to the requisite current range from "4mA" to "A" and set the meter to d.c. or a.c. with the function
button.
Note: If you do not know which range you require, start with the highest range and if need be repeat the measurement
in whichever lower range you then find to be required.
3. Apply the probes to the circuit to the measured.
5.4 Measuring resistance
1. Plug the black lead into the "COM" input terminal and the red lead into the "V-Ω" input terminal. (Note: The polarity of the
red lead is positive.)
2. Turn the function switch to "Ω
<" and use the function button to bring "Ω" up onto the display.
WARNING : To avoid the possibility of injury and to protect the meter from damage, make sure that the item from which
measurements are to be taken is not live.
3. Apply the probes to the item whose resistance is to be measured. To obtain the greatest possible accuracy with low
resistances, set the meter to the 400 Ω range, and before making a measurement short the probes together and press
the "REL" button. This will automatically correct for the resistance of the leads when subsequent measurements are made.
