3. Operation Instructions
3.1. AC Leakage Current Measurement
WARNING: Make sure that all the test leads are disconnected from the
meter's terminals for current measurement.
3.1.1. Leakage Current Flowing into Ground Conductor
a.Set the rotary switch at desired range.
b.Press the trigger to open the jaw and fully enclose the wire goes to
the ground. Make sure the two half jaws are properly closed.
c. Read the measured value from the LCD display.
