13
Electrical Specifications
˙Accuracy is ± (% of reading + LSD)
˙Ambient temperature: 23°C ± 5°C (< 80% RH)
Test Frequency
Model Frequency Accuracy
1705/1707
± 0.2%
1707 100kHz
100Hz
120Hz
1kHz
10kHz
Test Signal
AC Signal Level: 600mVrms
AC Signal Accuracy: ± 20%
DC Bias Level: 800mV
DC Bias Accuracy: ± 10%
When measuring by basic accuracy that following conditions
must be met:
˙ Ambient temperature: 23°C ± 5°C (< 80% RH)
˙ Open and short calibration have been performed.
˙ D ≤ 0.1 for C, L measurements; Q ≤ 0.1 for R measurements.
˙ Do not measure when charge by AC adaptor. It may cause
the reading rolling.
˙ See the operation manual for additional conditions.
D & Q
Definition: Q = 1/D = tanθ
Range: 2.000 to 2000
Minimum Resolution: 0.001
Accuracy: ± (0.5% + 5) x (1+D), when D < 1 or Q > 1
θ
Definition: θ = tan
-1
Q
Range: -90.0° to 90.0°
Minimum Resolution: 0.1°
Accuracy: ± (0.5% + 5)
