Iso-Tech LCR 1705 User Manual

14
Inductance
Range
100Hz
120Hz
1kHz 10kHz 100kHz
20.000uH N/A N/A N/A 0.5% + 30
[1]
200.00uH N/A N/A 0.5% + 30
[1]
0.5% + 5
2000.0uH N/A 0.5% + 30
[1]
0.5% + 5 0.5% + 5
20.000mH 0.5% + 30
[1]
0.5% + 5 0.5% + 5 1.0% + 5
200.00mH 0.5% + 5 0.5% + 5 0.5% + 5 N/A
2000.0mH 0.5% + 5 0.5% + 5 1.0% + 5
[2]
N/A
[1] Accuracy is specified after subtract of the offset inductance.
[2] < 50dgt rolling.
[3] If D > 0.1, the accuracy should be multiplied by .
2
1 D
Capacitance
Range
100Hz
120Hz
1kHz 10kHz 100kHz
200.00pF N/A N/A 2.0% + 1pF
[1]
2.0% + 1pF
[1][2]
2000.0pF 0.5% + 8
[1]
0.5% + 8
[1]
0.5% + 8
[1]
0.5% + 8
[1]
20.000nF 0.5% + 5 0.5% + 5 0.5% + 5 0.5% + 5
200.00nF 0.5% + 5 0.5% + 5 0.5% + 5 1.0% + 5
2000.0nF 0.5% + 5 0.5% + 5 1.0% + 5 N/A
20.000uF 0.5% + 5 1.0% + 5 N/A N/A
200.00uF 1.0% + 5 N/A N/A N/A
[1] Accuracy is specified after subtract of the stray capacitances for
test leads.
[2] < 50dgt rolling.
[3] If D > 0.1, the accuracy should be multiplied by .
2
1 D
