PARTS OF THE HOUSING
All camera controls are external and are laser-engraved with the symbols for the
camera functions.
Please refer to the Identication of Parts manual to see all controls of the housing.
All key Canon EOS 5D Mark IV Camera controls can be accessed.
The front ends with the port/lens mount hole that allows to mount different ports
(optional). Removable port -B120 mm bayonet.
On top of the housing there are 2 ber optic connectors and 2 Nikonos or S6 electric
bulkheads. One M16 hole for installation of accessories, e.g. vacuum valves or monitors
is also available.
Above, the single-hand closing knob for closing/opening the housing and detach the
back completely. M8 hole located on upper side of the housing for various accessories
such as focus lights, etc.
On both sides you can nd ergonomic side handles, adjustable (via optional accessory).
Wide, rubber covered feet on the bottom for solid footing.
Two M6 holes located on the bottom of the housing front side can be used for different
accessories such as brackets for strobes or tripods.
An easy and quick release camera mounting plate allows the camera positioning and
a lever locks the tray inside the housing. The tray is made of plastic material and is
provided with a not removable screw to x it on the housing.
A lever lock on the tray secures the camera when inserted. Insert the camera through
the two integrated guides of the plate support. Slide the lever to the right to lock the
camera on the plate; to release it slide it to the left.
Dual high-quality O-Ring seals on every movable part protect and ensure a perfect
and secure watertight.
FRONT
The handles of the DSLR housing are removable and adjustable in distance from the
housing via optional handles extensions.
Depending on the need they extend the space between the handles and the housing’s
body to improve their use even with gloves on.
It is also possible to use the T-socket or ball joint Ø 25 mm present on the handles to
attach various accessories.
HANDLES
INTERIOR
12
