ON
1 2 3 4
ON
1 2 3 4
If you have problems with strobes from SEA&SEA, INON, IKELITE and Subtronic
ash you switch the 1 / 2 / 3 pins on [OFF] as indicated in the gure below.
To insert SYNCRO CORDS
- To attach a strobe via electrical sync cord you have to use the bushings with
syncro socket placed on the side of housing.
N.B. A bulkhead cap or sync cord must be attached to the housing for waterproof
operation. Never submerge the housing without either a sync cord or waterproof
bulkhead cap attached.
-Remove the bulkhead cap by unscrewing the plug inserted into the socket
anticlockwise (to the left) with the help, if necessary, of a screwdriver or a coin.
-Line up the pins and receptacles and insert the sync cord plug into the housing
bulkhead. Attach the other end of the sync cord to the bulkhead on your strobe.
Then tighten the ferrule that acts as a safety.
Once the use of the ash is completed we recommended to remove the cable
connector of the ash from the attach and proceed with the closing of the plug.
Before buying a ash make sure it can be matched with the camera housing.
ATTENTION: to attach a strobe via electrical sync cord you have to use the bushings
with syncro socket placed on the side of housing. A bulkhead cap or sync cord must
be attached to the housing for waterproof operation. Never submerge the housing
without either a sync cord or waterproof bulkhead cap attached.
19
