iSystem iC5700 User Manual

Standard Debug Adapters
Various debug adapters are available to connect the iC5700 to a wide range target debug
connector as commonly found on microcontroller development boards.
Ordering Code
Description
IC50111-1
20-pin 2.54mm ARM Debug Adapter
IC50112
14-pin 2.54mm ARM Debug Adapter
IC50113-AMP
20-pin 1.27mm AMP CoreSight Debug Adapter
IC50115
38-pin Mictor ARM Parallel 16-bit Debug Adapter
IC50116-2
10-pin 1.27mm CoreSight Debug Adapter
IC50118-2
20-pin 1.27mm CoreSight Debug Adapter
IC50119
20-pin 1.27 x 2.54mm Compact TI-20 Debug Adapter
IC50150
14-pin 2.54mm MPC5xxx Debug Adapter
IC50152
38-pin Mictor MPC5xxx Nexus 16-bit Debug Adapter
IC50152-12
38-pin Mictor MPC5xxx Nexus 16-bit Debug Adapter
IC50156
50-pin ERF8 MPC5xxx Nexus 16-bit Debug Adapter
IC50160
16-pin 2.54mm Infineon JTAG Debug Adapter
IC50160-ECU14
10-pin 1.27mm TriCore ECU14 Debug Adapter
IC50160-MEDC17
10-pin 1.27mm TriCore MEDC17 Debug Adapter
IC50162
6-pin 2.54mm Infineon I2C Debug Adapter
IC50163-2
10-pin 1.27mm Infineon DAP2 Wide Debug Adapter
IC50164
22-pin ERF8 DAP2 Debug Adapter
IC50171
20-pin 2.54mm Renesas V850 Debug Adapter
IC50176
14-pin 2.54mm Renesas RH850 Debug Adapter
IC50176-EPS
10-pin 1.27mm Renesas RH850 Debug Adapter
IC50177
38-pin Mictor RH850 Nexus 16-bit Debug Adapter
Refer to the Debug Adapters User Manual for technical details on the listed debug adapters.
Find more information on www.isystem.com or contact sales@isystem.com. To reach
for technical support please visit www.isystem.com/support.
