ITC 10" User Manual

v.081118
13
ENGLISH
PARTS LIST
Please refer to the schematic drawing on pages following the parts list.
N
O.
DESCRIPTION QTY.
79 Limiter 1
80 M5 x 10 Phillips head countersink screw 1
81 Rubber limiter 1
82
Brand label 1
83
Depth adjustment nut 1
84 M6 x 35 bolt 1
85 M6 x 25 Allen screw 2
86
M6 nut 1
87 6202 Bearing 1
88 Lock spring 1
89
Shaft lock rod 1
90
Sleeve for shaft lock rod 1
91
Rotor 1
92 Carbon brush 2
93 6000 bearing 1
94 Fan shroud 1
95 ST4.8 x 70 Phillips head self-tapping screw 2
96 Stator 1
97 Phosphor copper spring 2
98
M4 x 10 Phillips head screw 6
99 Dia 4 spring washer 4
100 Self lock trigger 1
101 M3 x 8 Phillips head screw 1
102
Spring for trigger 1
103
Spring support 1
104 Circlip 1
105 Trigger sleeve 1
106
Self lock connection rod 1
107 Connection rod sleeve 1
108 Dust outlet 1
109
Dust bag 1
110 M5 x 20 Phillips washer head screw 1
111 Dia 5 spring washer 3
112
Washer 1
113
Transparent guard 1
114 Spring 1
115 M6 x 8 Phillips head screw 2
116
Spring plate 1
N
O.
DESCRIPTION QTY.
117 Transparent guard orientation plate 1
118 Screw for connection rod 1 1
119
Screw for connection rod 2 1
120 Dia 6 washer
1
121
Connection rod 1
122 Dia 6 washer
4
123
Dia 6 Spring Washer 5
124 M6 x 35 Phillips head screw 4
125 Brush holder cover 2
126
Brush holder 2
127 Housing 1
128
Rating label 1
129
M6 x 28 non-standard screw 1
130
Idler wheel 1
131
Spring plate 1
132
Rubber support for rotating table 1
133
Large washer 1
134 Dia 5 washer 2
135 Dia 8 steel ball 1
136
Spring 1
137 Dia 3 Hollow Pin 1
138
Small spring 1
139
M5 x 14 Phillips head screw 1
140 Felt wiper 2
141 Press ring 2
142 Lower D-handle 1
143 Capacitor 1
144 Inductance 2
145 Switch 1
146 Cable clamp 1
147 ST3.9 x 16 Phillips head self-tapping screw 8
148 Cable sleeve 1
149 Plug 1
150 Upper D-handle 1
151 Lift handle 1
152 ST6.3 x 20 Phillips head self-tapping screw 2
153 M5 x 45 Phillips head screw 2
154 ST3.9 x 12 Phillips head self-tapping screw 2
NOTE: The schematic drawing and parts list are subject to change without prior notice.
