PARTS LIST
Please refer to the schematic drawing on pages following the parts list.
N
O.
DESCRIPTION QTY.
1 Side extension 2
2 Winged screw 2
3 Rubber foot 4
4 Base 1
5 M5 non-standard screw 1
6 Steel plate for the rotating table 3
7 Rotating table 1
8 Battery storage cover* 1
9 Battery* 1
10 Battery box* 2
11 Laser* 1
12
Laser holder* 1
13
Mitre angle pointer 1
14 M6 x 14 Phillips screw 1
15 Connection rod support 1
16
Connection rod 1
17 M6 x 20 Phillips head countersink screw 2
18 M5 x 8 Phillips head screw 9
19
Plastic kerf plate (small) 1
20
Plastic kerf plate (large) 1
21
Dia 8 washer 1
22 M6 locknut 4
23 Rivet 2 x 4 2
24 Bevel indicator plate 1
25 M10 x 50 double-ended stud 2
26 M8 x 30 Allen screw 3
27 M8 Nut 2
28
Spring 1
29 Lock knob 1
30
Dia 10 washer 2
31
M10 locknut 1
32 Pin shaft cover 1
33 Lock spring 1
34 Lock lever 1
35 Pin shaft nut 1
36 Rubber orientation rod 2
37 Main support 1
38
Bevel angle pointer 1
39 M5 x 8 Phillips head screw 3
40 Lock knob 1
N
O.
DESCRIPTION QTY.
41 Safety guard lock pin 1
42 Connection support 1
43 M5 x 8 Allen screw 5
44 Depth adjustment plate 1
45 Dia 6 washer 1
46 Screw 1
47 Slide rod 2
48 Linear bearing 2
49 Rear cover 1
50 Pin 1
51 Spring 1
52 Fence 1
53 Dia 8 spring washer 4
54 M6 x 20 Phillips head screw 1
55 Winged screw 6 x 14 3
56 Clamp shaft 1
57 Clamp cross bar 1
58 Clamp knob 1
59 Screw 1
60
Clamping plate 1
61
Dia 5 washer 4
62 Socket wrench 1
63 M8 x 20 Allen screw 1
64 Outer ange 1
65 Blade 1
66 Blade orientation ring 1
67 Inner ange 1
68
M5 x 16 Phillips head screw 2
69 Bearing retention plate 1
70 Output shaft 1
71 Pin 1
72 6203 bearing 1
73 Bearing housing 1
74 Large gear 1
75 Dia 17 circlip 1
76 HK121610 needle bearing 1
77 Safety guard 1
78 M4 x 10 Phillips head countersink screw 2
* NOTE: The laser unit is not included in this model.
