ITC TS-3400MIXD - Specification

- 6 -
2.3 Specification
Model
TS-3400MIXD
Number of open microphone
16 wired mics + 8 wireless mics
Frequency response
80Hz ~ 16kHz
SNR
> 75dB(A)
Dynamic range
>75dB(A)
THD
<0.05%
Main power supply
100-240AC/50-60Hz
Audio output
LINE OUT 1: 1V XLR balanced output ;
LINE OUT 2: 1V RCA unbalanced output
Output load
>1KΩ
Static power consumption
3.3W
Connection method
RJ45 network port
Indicator light
AFC function indicator, audio signal indicator, working status
indicator, power indicator
Working temperature
-10℃~+60℃
Working humidity
20%～80% relative humidity, no condensation
Weight
2.51Kg
Dimension (L×W×H)
484×214×44mm
Installation method
19-inch standard cabinet
