Set the
levels/voltages/duration of
starting profile
The levels of 12V: 1-4
The levels of 24V: 1-3
Off
Enable/Disable this function
On
Load-Dump
Load dump curve
Test A select centralized load dump
Unsuppression
Test B
select centralized load dump
suppression
Off
Turn on/off load dump
waveform
On
12V
Select 12V or 24V voltage
system
24V
Td
Pulse width
Un
Peak voltage
Us
clamping voltage
ISO21848
Simulate the curve of “Electrical and electronic equipment
for a supply voltage of 42 V — Electrical loads”
Umax,dyn
Umax,dyn Test pulse
Off
Turn on / off Umax,dyn test
pulse
On
Momentary-
Drop
Transit Voltage drop
Off
Turn on / off transit Voltage
drop wave
On
Reset
Reset test supply Voltage
Ulow
Set supply Voltage
Off
Turn on /off rest test function
On
Start
Startup pulse
Off
Turn on /off startup pulse
On
SAEJ1113-1
1
SAEJ1113-11 waveform protocol
Test 2B
Transient from DC motors acting as
generators after ignition switch OFF
Off
Turn on/off this function
On
12V
Select 12V or 24V voltage
system
24V
Td
Test pulse width
Test 4
Starter motor engagement disturbance pulse
Off
Turn on/off this function
On
12V
Select 12V or 24V voltage
system
24V
Vs
Refer to the figure
Va
-
T7
-
T9
-
