Function and Features
Copyright ©ITECH Electronic Co., Ltd. 28
(Voltage
monitoring)
Voltage monitoring terminal, the output analog range is 0~10V,
used to monitor the output voltage between 0~voltage full scale,
take IT6942B as an example, when the voltage output from this
terminal is 5V, the corresponding output voltage of IT6942B is
30V.
Pin7
Im
(Current
monitoring)
Current monitoring terminal. The output analog range is 0~10V,
which is used to monitor the output current between 0~current
full scale. Take IT6942B as an example, when the voltage
output from this terminal is 5V, the corresponding output current
of IT6942B is 7.5A.
Pin8
NULL
This pin is null.
Pin9
GND
Common reference ground for input/output analog and input
digital.
