iTechworld 3000W - Front Panel Overview (3000 W); 3000 W Hard-wire Terminal Block

Front Panel Continued
Figure 2- 3000W inverter front panel
A
AC Output Receptacle
B
Main Switch
C
Power LED Indicator
D
Fault LED Indicator
E
5V USB Socket
F
Remote Control Port (RJ11) For connecting the optional remote-
control switch panel.
G
Chassis Ground Terminal
H
Hard-wire terminal block for use if loads are 15A or more
(MUST BE CONNECTED BY A LICENSED ELECTRICIAN)
