SERVICE MANUAL

E-9

Insert the spring (35) and ball (34) into the housing (15).

Insert the special tool CA715620 into the housing (15).

See: sec. C.4. and sec E.1. (4WD mechanical drop box).

Push with a punch the ball (34) on the spring (35) then insert the special tool

CA715620 on the ball (34).

Insert the fork shaft (33) in the housing (15) pushing forward the special tool

CA715620.

Collect the special tool CA715620.

FIG. 4

FIG. 5

FIG. 6

FIG. 7
