ITL SERVICE MANUAL
B-36
Step 34
Screw valve lubrication bolt (M10x1.5) & lock it with nut M10.
Step 32
Fit HPD shaft assy in crankcase and tighten it with retainer by
using three ScrewsM8x14.
Step 33
Fit HPD shaft gear in such a manner that Projected side of gear
should be towards the crankcase (as shown in Fig.) and tighten it
with nut M30x1.5.
