SERVICE MANUAL

B-40

Step 47

Lubricate TIG & fit in such a way that its timing mark match with

cam gear, crank gear & FIP Timing Gear .

Step 48

Place lock plate over TIG and tight it with bolts M8x45.

Step 49

Fit tube assy. from lubricating bolt to TIG pin.
