SERVICE MANUAL
B-55
Step 96
Fit breather pipe with side cover using banjo bolt B-13 along with
sealing washer (18x24x1.5 CU).
Step 97
Mount exhaust flange and tighten it with M10nuts and B10 washer .
Fit two studs M10*30 in exhaust flange for exhaust elbow mounting.
.
Step 98
Place injector along with sealing washer in each cyl head and tighten
Injector clamp alongwith conical washer and M8 nut. Tight M8 nut properly.
Step 99
Fit water pump along with gasket to front side of crankcase using 3 bolts
M10x35 and spring washer B-10 & one bolt of M10*40 and tight properly..
ITL
