Acupuncture-Point Search/Stimulation Mode
Set the Search/Stimulation Probe.
Note:
※The Search/Stimulation Probe allows the application of current stimulation to a local area.
※One end of the Search/Stimulation Probe is made of metal. The probe is used with the other end stuffed
with purified cotton soaked in water. Either end can be used. (Wring the water from the soaked cotton
before using the probe.) It is recommended to use a cotton cone soaked in water. Keep in mind that when
the metallic part of the probe is applied to the skin, that portion of the skin may turn red in some cases.
Turn on the unit and press the Search/Stimulation selector key. When the
Search/Stimulation mode is selected, the Search/Stimulation mode indicator
lamp will light up in green.
Insert one plug of the Search/Stimulation Probe cord
into the Output port of CH1, and the other plug into the
Search/Stimulation Probe insertion port (blue mark).
Have the patient hold the grounding rod, and apply the tip of the Search/Stimulation
Probe to the patient's skin. When the stimulation button of the probe is pressed in
an area of the skin at which the resistance is low, the stimulation output will be
delivered. Before treatment, the Output intensity knob should be set to the “0”
position. Otherwise, the alarm will sound, and the Error lamp will come on.
Confirm that the Output intensity knob of CH1 is set to “0.” Otherwise, a warning
sound will be emitted and the Error lamp will come on.
While the Search/Stimulation mode is activated, CH2 to CH6 cannot be used.
1
2
3
4
Grounding
rod
Search/
Stimulation
Probe
Prepare a suitable cotton
cone soaked in water and
wring it enough.
And place it over one
end of the probe.
The portion of the cotton
cone soaked should be
applied to the skin.
To Next Page
