TROUBLESHOOTING RC-100DX.RC-115DX.RC-137DX
CONTENTS
Power Supply.................................................................................. 1
・ The power is not turned ON, and the power is turned OFF... 1
T.D.C Lamp Lights Up..................................................................... 1
Main Motor ...................................................................................... 1
・ The main motor cannot be started up. ............................... 1
Display On Computer Display Unit.................................................. 2
1 The present position of backgauge is not displayed. ............. 2
2 "Err" is displayed............................................................... 2
Clamp.............................................................................................. 3
1 The clamp does not lower and the speed is low
when the clamp pedal is worked.
........................................... 3
2 The clamp does not lower when the clamp pedal is worked,
and the speed is low..
........................................................... 3
3 The clamp pressure during paper cutting is abnormal. .......... 4
4 Pressure set value reference data ...................................... 4
Knife Drive ........................................................................................ 5
1 Knife & clamp operation is not carried out............................ 5
2 The knife does not operate................................................. 5
3 The knife stops halfway. .................................................... 6
・ Knife circuit interruption due to power-OFF .................... 6
・ Insufficient holding time for cutting buttons ON-state....... 7
・ Loose knife supporting bolt .......................................... 7
・ Loose safety bolt ........................................................ 7
・ Safety beam guard operation ....................................... 8
・ Knife circuit error ........................................................ 8
Backgauge...................................................................................... 9
1 Abnormal noise during backgauge travelling........................ 9
2 The backgauge does not operate........................................ 9
Blower........................................................................................... 10
1 The blower motor cannot be started up. ............................ 10
2 Insufficient air blow amount.............................................. 10
3 Air blow/stop control error................................................ 10
4 Abnormal noise .............................................................. 10
