ICE QUEEN
TECHNICAL SERVICE MANUAL
15
Green button: Starts the machine. It is indicated with the led on.
Red led: Shows that the machine is stopped by the security element.
Orange led: Shows that the bin is full.
IQ 50 - 85
Orange Led
Red Led
Green Button
Green button: Starts the machine. It is indicated with the led on.
Red led: Shows that the machine is stopped by the security element.
Orange led: Shows that the bin is full.
