ITV IQ 50 - Page 18

ICE QUEEN
TECHNICAL SERVICE MANUAL
18
MODEL
HIGH PRESURE
LOW
PRESURE
AVERAGE
TOTAL
AMPS
(2)
(A)
FUSE
RATING
(A)
COMPRESSOR
POWER
(1)
(W)
TOTAL
POWER
(2)
(W)
MINIMUM
MAXIMUM
Kg/cm
2
Psi
Kg/cm
2
Psi
Kg/cm
2
Psi
IQ 150 A
16
228
17
242
2.5
35
4.2
16
365
660
IQ 150 W
16
228
17
242
2.5
35
4.2
16
365
660
IQ 200 A
16
228
17
242
2.5
35
4.6
16
440
800
IQ 200 W
16
228
17
242
2.5
35
4.6
16
440
800
IQ 400 A
16
228
17
421
2.5
35
5.8
16
690
1100
IQ 400 W
16
228
17
242
2.5
35
5.8
16
690
1100
IQ 550 A
16
228
17
242
2.5
35
9.2
20
1000
1700
IQ 550 W
16
228
17
242
2.5
35
9.2
20
1000
1700
(1) Data obtained at room temperature (20°C), water introduced at 15°C; water quality = 500ppm
(2) Maximum consumption obtained at room temperature = 43°, according to UNE climate classification
Class T (TROPICALISED).
NOTE: Expansion controlled by capillary, except for model IQ400 and 550 which is controlled by a
thermostatic valve.
Models: ICE QUEEN 400 & 550 380V+III+N
MODEL
HIGH PRESURE
LOW
PRESURE
AVERAGE
TOTAL
AMPS
(2)
(A)
FUSE
RATING
(A)
COMPRESS
OR POWER
(1)
(W)
TOTAL
POWER
(2)
(W)
MÍNIMUM
MÁXIMUM
Kg/c
m
2
Psi
Kg/c
m
2
Psi
Kg/c
m
2
Psi
IQ 400 A
16
228
17
242
2.3
33.4
3.5
10
750
1350
IQ 400 W
16
228
17
242
2.3
33.4
3.5
10
750
1350
IQ 550 A
16
228
17
242
2.3
33.4
5
16
2200
2x2700
IQ 550 W
16
228
17
242
2.3
33.4
5
16
2200
2x2700
NOTE: Expansion controlled by a thermostatic valve.
