7 Functional check
The colour of the status LED’s on the anti-static bar can be used to determine the status of the
anti-static bar.
Operation Bar LED
ThunderIon
Bar Led
ThunderIon IQ
Standby Green flashing Green flashing
In operation Green on Green on
Overloaded Red on Red on
Clean bar warning N.A. orange
HV OK output overload Red flashing N.A.
Internal error Red flashing Red flashing
No communication N.A Red flashing (quick)
N.A: not applicable
Possible causes of overload are:
- Fouling of the anti-static bar.
- Direct contact between conductive material and the emitters.
- The anti-static bar has been fitted too close to conductive (machine) parts.
Possible causes of HV OK output overload are:
- Short circuit of the HV OK output signal
- Excessive load of the HV OK output signal
7.1 Power up & pulse frequency indication ThunderION
Green flashing quick for 2 seconds
Pulse-frequency indication:
Red flashing quick 10x,
green flash (amount of flashes = pulse frequency [Hz])
Red flashing quick 10x,
Standby (green flashing) or operating mode (green on)
7.2 Power up & communication checkThunderION IQ
Green flashing quick for 2 seconds
Communication check
green flash for maximum 5 sec.
Standby (green flashing), operating mode (green on)
or no communication (red flashing quick)
7.3 External: Bar HV operating OK output ThunderION
The external Bar HV operating OK output is active if the following three conditions are met:
the supply voltage is present on the M12 connector
the bar is Remote On/Off input is activated on the M12 connector,
there is no error.
