Ivation IVASTEAMR20 User Manual

4
• When using this product, the surface you are cleaning may become wet. This is because the steam reverts
back to a liquid state upon coming into contact with the surface. Simply wipe away the moisture with a
sponge or a cloth.
FILLING THE STEAM CLEANER
Before filling the steam cleaner, follow the precautions below:
• Make sure the unit is o, unplugged, and has been given time to cool for at least ten (10) minutes.
• Unlock the steam trigger to ensure there is no more steam coming from the unit.
• If you are living in an area with hard water, it is recommended to use distilled or filtered water instead.
ATTACHING ACCESSORIES
IMPORTANT: Be sure to attach the accessories BEFORE turning on the unit. Otherwise, there is a risk of
experiencing severe burns.
1. Press and hold the button located on the handle.
While holding it down, slide on the desired
attachment.
2. When the attachment is securely in place, the
button will raise to lock it in place.
1. Turn the cap counterclockwise to remove it.
2. Use the included funnel and measuring cup to carefully fill the water tank. Be careful not to overfill it.
3. Replace the cap, turning it clockwise until it is sealed.
Note: if the cap will not unscrew, reduce the pressure in the unit by squeezing the steam trigger.
Note: The maximum water capacity of the water tank is four (4) pints. However, it is not recommended
to fill the tank to max capacity. Instead, fill it no more than 3.8 pints.
REMOVE REPLACE
1
2

Ivation IVASTEAMR20 Specifications

Operating Environment

max temperature	338°F (170°C)
max pressure	65 PSI (5 bar)
working pressure	29–65 PSI (2–5 bar)

Power

power consumption	1800 W
intensity	15.0 A
voltage	120 V
frequency	60 Hz

Water Tank

water tank capacity	3.8 pints (1.8 L)
max tank fill capacity	4 pints (1.95 L)
warm up time	7 min

Weight and Dimensions

tube length	1.45m
net weight	8 lbs. (3.6 kg)
steam compartment material	stainless steel
