IVEK DIGISPENSE 3009 - Page 29

DIGISPENSE 3009 CONTROLLER MODULE, STYLE B Page 3-29
29 October, 2019 IVEK Corp. P03R017E
3.3.7.11 Fault Screen
Keylock/Supervisor
D = Display P = Push-button Accessible I/O Test
C = Display/Change N = Not Accessible/Viewable Operator
0 FAULT <— status —>
2
3 Piston Home Fault
4 Error Code: ##########
5
6
7
8
9
10
11 “CLEAR FAULT” = CLEAR FAULT & REFERENCE
12 “SETUP A SCREEN” = CHANGE VALUES FIRST
13
14 SETUP A CLEAR
15 SCREEN FAULT
----- Displays the Controller Module status ......... D D D
----- Displays the fault description ....................... D D D
----- Displays the fault error code ........................ D D D
----- Clears the displayed fault ............................ P P P
----- Switches to the Setup A screen ................... P P P
