3.4.7.3 Agitate Screen
Keylock/Supervisor
D = Display P = Push-button Accessible I/O Test
C = Display/Change N = Not Accessible/Viewable Operator
0 AGITATE <— status —>
2
3 VOLUME AGITATED = ###### STROKES
4
5
6 RECIPE = ##
7 AGITATE DIRECTION = FORWARD
8 AGITATE VOLUME = ##### STROKES
9 AGITATE RATE = #### RPM
10
11 AGITATE DWELL = #.## SEC.
12 ISOLATION VOLUME = ##### STROKES
13
if dispense mode
14 *DISPENSE SETUP A GET
15 SCREEN SCREEN RECIPE
OR if disabled production mode
14 SETUP A GET
15 SCREEN RECIPE
OR if NO motor/base selected
14 DISPENSE SETUP A SETUP C GET
15 SCREEN SCREEN SCREEN RECIPE
OR if reference recommended
14 DISPENSE SETUP A REFERENCE GET
15 SCREEN SCREEN RECIPE
OR if get recipe disabled
14 DISPENSE SETUP A
15 SCREEN SCREEN
NOTE
*Field 3 will display DISPENSE SCREEN when in
Dispense mode or METER SCREEN when in Meter
mode.
----- Displays the Controller Module Status ........ D D D
----- Displays the agitated volume ....................... D D D
----- Displays the current recipe .......................... D D D
----- Display/change the agitate direction ............ D D D
----- Display/change the agitate volume .............. D D C
----- Display/change the agitate rate ................... D D C
----- Display/change the agitate dwell ................. D D C
----- Display/change the isolation volume ........... D D C
The following screens are accessible from
this screen based on the system status.
Dispense .............................................................. P P P
Setup A ................................................................ P P P
Get Recipe ........................................................... P P P
Meter .................................................................... P P P
Setup C ................................................................ P P P
