DIGISPENSE 3009 CONTROLLER MODULE, STYLE B Page 3-44
29 October, 2019 IVEK Corp. P03R017E
Agitate Screen Description - The Agitate screen displays the current Agitate parameters and allows a user with Supervisor
permission to change the parameters. The current permission level determines which push-buttons are available as shown.
The Start and Stop push-buttons control Agitate operation while this screen is visible.
Status - The status indicates the operational state of the system. Refer to section 3.3.8 for an explanation of each
status type.
Volume Agitated - The Volume Agitated line shows the total number of strokes of the motor during agitation
operation. The total strokes counter will go up to a maximum of 120,000 and will return to 0 upon completion of the
agitate cycle (unless terminated pre-maturely).
Recipe - The Recipe line shows the current recipe selected in the Recipe screen. "0" indicates values changed since
last "Get Recipe".
Agitate Direction - The Agitate Direction is the direction of liquid flow through the Pump Module for the Agitate mode.
The direction is either Forward or Reverse.
Agitate Volume - The Agitate Volume is the amount of fluid to agitate in strokes during an agitate cycle. The range is
1 to 60,000 with an increment value of 1.
Agitate Rate - The Agitate Rate is the rate of the motor in RPM's during the agitate cycle. The range is 1 to 1,500
with an increment value of 1.
Agitate Dwell - The Agitate Dwell is the time between the forward and reverse cycles in seconds. The range is 0.00
sec to 300.00 sec with an increment value of 0.01.
Isolation Volume - The Isolation Volume is the amount of liquid isolated prior to the agitate cycle in strokes. The
range is 0 to 60,000 with an increment value of 1.
To change a value;
1. Press the Arrow push-buttons to highlight the parameter.
2. Press the Enter push-button to bring up either the Select New Value or Enter New Value screen.
3. In the Select New Value screen use the up and down arrow push-buttons to select the value. In the Enter New
Value screen press the Minimum or Maximum push-buttons to select the desired value or use the left and right
arrow push-buttons to select the digit and the up and down arrow push-buttons to change the digit's value.
4. Press the Enter push-button.
NOTE
Changing Agitate Volume, Agitate Rate or Agitate Direction does not affect the settings of Dispense and
Meter mode. However, they do affect Prime mode.
