IVEK DIGISPENSE 3009 - Page 53

DIGISPENSE 3009 CONTROLLER MODULE, STYLE B Page 3-53
29 October, 2019 IVEK Corp. P03R017E
3.4.7.8 Setup C Screen
Keylock/Supervisor
D = Display P = Push-button Accessible I/O Test
C = Display/Change N = Not Accessible/Viewable Operator
0 SETUP C <— status —>
2
3 MOTOR/BASE = #
4
5 STALLS PER FAULT = # STALLS
6
7 STOP POSITION = ## DEG
8
9 TORQUE = MEDIUM
10 ACCELERATION = MEDIUM
11 INITIAL RATE = HIGH
12
13
14 SETUP B SYSTEM REFERENCE CLEAR
15 SCREEN INFO TOTALIZER
----- Displays the Controller Module Status ........ D D D
----- Display/change the motor/base type ........... D D C
----- Display/change the stalls per fault setting ... D D C
----- Display/change the stop position ................. D D D
----- Display/change the torque setting ............... D D C
----- Display/change the acceleration setting ...... D D C
----- Display/change the initial rate setting .......... D D C
The following screens are accessible from
this screen based on the system status.
Setup B ................................................................ P P P
System Info .......................................................... P P P
Clear Totalizer ...................................................... P P P
